JMC Slow Building Electric Windlass Commercial Model Electric Winch
JMC Slow Building Electric Windlass Commercial Model Electric Winch
JMC Slow Building Electric Windlass
Slow Building Electric Windlass
JMC
Commercial Model
Model | Cable rated pull | Cable rated | Wire Rope | Wire length | Drum (mm) | Motor Power | Weight(kg) | |
Without rope | With rope | |||||||
JMC0.5 | 500 | 16 | 7.7 | 100 | 175 | 4.2 | 129.5 | 150 |
JMC1 | 1000 | 16 | 9.3 | 160 | 218 | 5.5 | 170 | 200 |
JMC1.5 | 1500 | 16 | 11 | 200 | 255 | 5.5 | 308.1 | 350 |
JMC2 | 2000 | 16 | 12.5 | 200 | 275 | 7.5 | 446 | 460 |
JMC3 | 3000 | 16 | 15.5 | 200 | 315 | 11 | 517 | 550 |
JMC5 | 5000 | 9 | 19.5 | 250 | 400 | 11 | 1280 | 1437 |
JMC8 | 8000 | 10 | 26 | 300 | 475 | 15 | 2850 | 3201 |
JMC10 | 10000 | 9 | 30 | 300 | 515 | 22 | 3200 | 3667 |
JMC16 | 16000 | 9 | 36.5 | 400 | 717 | 30 | 5200 | 6120 |
JMC20 | 20000 | 10 | 39 | 450 | 950 | 45 | 7500 | 8659 |
JMC30 | 30000 | 10 | 47.5 | 450 | 1100 | 55 | 9200 | 10916 |
